DCM250C – Live Electrical 2 Pole 50A C Curve 6kA DC MCB

The Live Electrical DCM250C is a compact 2 Pole 6A DC miniature circuit breaker, ideal for protecting low-current solar panel strings and DC control systems. With a 500V DC voltage rating and 6kA breaking capacity, it offers safe and effective circuit isolation.

This MCB features a C curve thermo-magnetic tripping mechanism, designed to respond reliably to overloads and short circuits in DC circuits. It mounts securely to TH35-7.5 DIN rails and supports 16mm² maximum terminal capacity. Certified to IEC/EN 60898-2 and protected to IP20.

 Key Features – Live Electrical DCM250C 50A DC MCB

• 2-pole DC miniature circuit breaker
• Rated current: 50A
• Rated voltage: 500V DC
• Breaking capacity: 6kA
• C Curve thermo-magnetic tripping
• Mounts on TH35-7.5 DIN rail
• IP20 contact protection
• Maximum terminal capacity: 16mm²
• Conforms to IEC/EN 60898-2
