The Ei168RC RadioLINK Base is an easi-fit mounting
plate with built-in RadioLINK. It provides wireless interconnect between
alarms, i.e. when one alarm is triggered, all alarms in the system sound. It is
mains powered unit with a rechargeable lithium cell back-up, to be used instead
of the easi-fit base to enable the alarms to have RadioLINK capabilities. The
Ei168RC RadioLINK base is compatible with the 140RC Series alarms – Ei146RC, Ei144RC & Ei141RC.

The 160e Series and Multi-Sensor Fire
Alarm use a RadioLINK Module, Ei100MRF, directly into the head
of the alarm to gain RadioLINK+ capabilities instead of a base.

Once all the alarms have been installed the RadioLINK system
is secured by a special House Coding function to safeguard the system
from interference from other RF systems.

The Ei168RC allows for easy expansion of an existing hard-wired
interconnected system. A mixed wired and wireless system is often referred to
as a hybrid system. To set a hybrid system up – Simply
fit one Ei168RC base to an alarm in the existing alarms and any new
alarms with Ei168RC bases. Once installation is complete House Code the alarms
together into a system. If any alarm, hard-wired or wireless, is now triggered
it will sound all the alarms in the system.

Key Features

• Mains
  powered base with rechargeable lithium cell back up




• Add
  this to the 140RC series alarms for RadioLINK wireless
  interconnection




• Compatible
  with other Aico wireless interconnection products




• Eliminates
  tricky wiring runs




• Saves
  time, mess and money




• Makes
  it easier to add in new alarms and accessories
